DR-CG-2310-002-B-PT DR-CG-2310-002-B-PT Dura-Lite USA Plastic Tank/ Aluminum Core Radiator - No Frame - With Oil Cooler (Driver Side - Engine Oil Cooler with ½“ Quick Connect Fittings on 10” [254.0mm] centers) - With Filler Neck (Passenger Side top corner), Low Coolant Sensor Fitting and Plug, ¾” NPT Low Coolant Sensor Fitting, and Ø1 5/16” [33.3mm] OD Inlet and Outlet Connections.
Dura-Lite™ Radiator - No Frame - Oil Cooler (1 Year Warranty)

DR-CG-2310-002-B-PT

Description

Plastic Tank/ Aluminum Core Radiator - No Frame - With Oil Cooler (Driver Side - Engine Oil Cooler with ½“ Quick Connect Fittings on 10” [254.0mm] centers) - With Filler Neck (Passenger Side top corner), Low Coolant Sensor Fitting and Plug, ¾” NPT Low Coolant Sensor Fitting, and Ø1 5/16” [33.3mm] OD Inlet and Outlet Connections.

Product Option Descriptions

Plastic Tank/ Aluminum Core Radiator - No Frame - With Oil Cooler (Driver Side - Engine Oil Cooler with ½“ Quick Connect Fittings on 10” [254.0mm] centers) - With Filler Neck (Passenger Side top corner), Low Coolant Sensor Fitting and Plug, ¾” NPT Low Coolant Sensor Fitting, and Ø2” [50.8mm] OD Inlet and Outlet Connections

Plastic Tank/ Aluminum Core Radiator - No Frame - With Oil Coolers (Driver Side - Engine Oil Cooler with ½“ Quick Connect Fittings on 10” [254.0mm] centers and Passenger Side - Transmission Oil Cooler with 1 1/16” ORB Fittings on 18” [457.2mm] centers) - With Filler Neck (Passenger Side top corner), 1/8” NPT Low Coolant Sensor Fitting, and ¾” NPT Low Coolant Sensor Fitting

Plastic Tank/ Aluminum Core Radiator - No Frame - With Oil Coolers (Driver Side - Engine Oil Cooler with ¾” ORB Fittings on 7” [177.8mm] centers and Passenger Side - Transmission Oil Cooler with 1 1/16” ORB Fittings on 18” [457.2mm] centers) - With Filler Neck (Passenger Side top corner) and ¾” NPT Low Coolant Sensor Fitting

Plastic Tank/ Aluminum Core Radiator - No Frame - With Oil Coolers (Driver Side - Engine Oil Cooler with ¾” ORB Fittings on 7” [177.8mm] centers and Passenger Side - Transmission Oil Cooler with 1 1/16” ORB Fittings on 18” [457.2mm] centers) - With Filler Neck (Passenger Side top corner), 1/8” NPT Low Coolant Sensor Fitting, and ¾” NPT Low Coolant Sensor Fitting

Warranty

North American wide coverage.

Dura-Lite’s warranty is not prorated and warrants the original vehicle installation for a period of 1 (one) year from the date of installation (unlimited mileage) that its Radiators (the “Radiator”) will remain free from defects in material and workmanship under normal on-highway operating conditions.

All products are tested to be 100% leak free before they leave the manufacturing facility.

Read more...

Product Specifications

Core Dimension - Header to Header:

Core Dimension - Over Sidepieces:

Inlet Connection OD Dimension:

Inlet Connection Note:

Outlet Connection OD Dimension:

Outlet Connection Note:

31 7/16" 23 5/16" 1 5/16" OD 1 5/16" OD
